How to install window air conditioner? Window machine air conditioning installation method
Window air conditioner, as its name suggests, is an air conditioner that can be installed on a window. The air conditioner of the window machine is similar to the air conditioner product we use every day, but the installation method is different, so how to install the window air conditioner? Window air conditioner installation methods and precautions, I hope to be able to help everyone.
How to install window air conditioner?
Window machine air conditioning installation method:
1. After determining the installation position, measure the size of the air conditioner of the window machine and open the installation hole as required. If the house has been made into a reserved hole and bracket for the window air conditioner during construction, the reserved hole should be inspected and corrected ; if all the reserved holes around the house are blocked, the two sides should be opened to avoid suction. The wind is blocked.
2. Fix the mounting bracket. Secure the mounting bracket to the intended mounting position, and use a level to detect and calibrate to the level. The outside of the mounting bracket should be 6-10 mm below the inside .
3. Remove the panel, air filter and chassis fixing plate, pull the chassis together with the components fixed on the chassis from the outer box, then place the casing on the mounting bracket, use the level to detect and correct to the level, and use bolts. Fix it, push the chassis and the whole part horizontally into the outer box, install the chassis fixing plate ; and note that the air conditioner of the window machine should be tilted 6-10mm backwards and downwards , and the water spout should be installed to ensure the smooth condensation. discharge.
4. Use the level meter to check whether the air conditioner of the window machine is level (whether the base is not flat or even twisted), otherwise there will be abnormal noise and vibration during the operation of the air conditioner in the window machine, which will affect the relative positional deviation of the components of the air conditioner of the window machine.
5. Reinstall the air filter and panel and fix it. Inspect the side air intake for blockage and fill the case with a sponge or foam.
6, drainage, the general window air conditioner will have condensed water discharged from the window air conditioner.
7. Grounding should be considered with safety as the priority. The installer should check whether the power socket provided by the user has been effectively grounded.
8. Trial operation, power-on test operation after all installations are completed. Window machine window air conditioner generally does not need to be debugged by the system. The installer only needs to test whether the sound and function are normal. The difference between the inlet and outlet air temperature is generally greater than 8 °C.
Window machine air conditioner installation precautions:
When installing the air conditioner of the window machine , in order to prevent the blinds on both sides of the outdoor from being blocked, the indoor ventilation is not smooth, and the rear part of the air conditioner should maintain a space of more than 1 meter. The location of the air-conditioning installation should be a little farther from the door, away from the heat source, reducing unnecessary vibration of the air conditioner. The height of the air conditioner installation is best between 1.5 and 2 meters. After the air conditioner is installed, it is necessary to maintain a height difference of 1 to 3 cm between the indoor and outdoor, so that the condensation water can flow out of the outdoor, and to protect the air conditioner, a sun visor can be installed above the air conditioner.
The above is how to install the window air conditioner for you. Detailed explanation of the installation method of window air conditioners, I believe that everyone has a basic understanding of window air conditioner installation after reading this article, if you want to know more about decoration consultation, please click to enter the decoration knowledge channel .
