3 and 5 Gallon Barrel Water Filling Machine/ Buckets Bottling Line
Model NO.: XGF 16-16-5
Packaging Technology: Mildew Proof Packaging
Application: Drinks, Oil, Tea, Vegetable, Fruit
Soft and Hardness: Flexible Package
Circulation Function: Outer Packing
Frequency of Use: Several Packaging
Mode of Operation: Packaging of Export Products
Material Type: Stainless Steel
Filling Machine: Water Filling Machine
Color: Metal Color
Price: Low Price
Water Filling Line: Pure Water Filling Line
Quality: The Regional Top
Control: PLC
Volume: 5 Gallon
Production: Pure Water Filling Machine
Trademark: china beverage
Transport Package: Wooden Case
Specification: 3550*800*1800 mm
Origin: China
HS Code: 8422301090
Model NO.: XGF 16-16-5
Packaging Technology: Mildew Proof Packaging
Application: Drinks, Oil, Tea, Vegetable, Fruit
Soft and Hardness: Flexible Package
Circulation Function: Outer Packing
Frequency of Use: Several Packaging
Mode of Operation: Packaging of Export Products
Material Type: Stainless Steel
Filling Machine: Water Filling Machine
Color: Metal Color
Price: Low Price
Water Filling Line: Pure Water Filling Line
Quality: The Regional Top
Control: PLC
Volume: 5 Gallon
Production: Pure Water Filling Machine
Trademark: china beverage
Transport Package: Wooden Case
Specification: 3550*800*1800 mm
Origin: China
HS Code: 8422301090
3 and 5 Gallon Barrel Water Filling Machine/ Buckets Bottling Line
Barrel/ compression barrel filling line
1. Applicable prouducts: Pure water, mineral water,etc.(3L-20L)
2. Suitable containers: PET barrels, PP barrels, PC barrels
3. Filling principle: Gravity, weighing, flowmeter filling
4. Filling temperature: Room temperature
5. Production capacity: 1000BPH-4000BPH
Product Description
This filling line specially for 3-5gallons barreled drink water, with type QGF-100, QGF-240, QGF-300, QGF-450, QGF-600, QGF-900, QGF-1200, It intergrates bottle washing, filling and capping into one unit, In order to achieve the purpose of washing and sterilizing, The washing machine use multi-washing liquid spray and-thimerosal spray, This thimerosal can be used circularly, The capping machine can cap barrel automatically, this line equips with water spraying device in order to ensure those caps sterilizer and clean. It also can automatically carry out barrel, washing, sterilizing, filling, capping, counting and products discharging, with complete function, modern design and high degree of automation, it is a new kind of barreeled water auto-production line, which intergrates mechanism, electricity and pneumatics technologies together.
It is the ideal equipment for mineral water, distilled water and purified water producing process. The machine is made of excellent stainless steel with the advantage of easily-rinsing and corruption-resistance. The main electrical parts adopt products with brand of SIEMENS and OMRON. Pneumatic parts adopt products with brand of AIRTAC. Both the inner and outer shower nozzle for washing barrel adopts the special technology equipment from American Sprayer Company. The machine works reliably and efficiently based on the compact structure and high automatic technology. It is the fully automatic barreled water producing equipment combined with machine, electronic and pneumatic components.
Fucntion:
1. It is specially used for filling 3 gallon to 5 gallon bottled water.
2. It is a good machine line for the all shapes of bottles.
3. The machine is designed for bottles such as PVC. PE. PET etc. It can be used for different shapes of bottles.
4. The machine line with stainless steel rinse nozzles, pressure filling valve, screw capper, hot steam film shrinkage machine top quality line.
5. Filling time is controlled by the PLC.
6. The machine adopts high quality stainless steel frame(No. Z304).
7. The machine design appreance is beautiful, easy operation, maintainence and working stable
Â
It is the ideal equipment for mineral water, distilled water and purified water producing process. The machine is made of excellent stainless steel with the advantage of easily-rinsing and corruption-resistance. The main electrical parts adopt products with brand of SIEMENS and OMRON. Pneumatic parts adopt products with brand of AIRTAC. Both the inner and outer shower nozzle for washing barrel adopts the special technology equipment from American Sprayer Company. The machine works reliably and efficiently based on the compact structure and high automatic technology. It is the fully automatic barreled water producing equipment combined with machine, electronic and pneumatic components.
Fucntion:
1. It is specially used for filling 3 gallon to 5 gallon bottled water.
2. It is a good machine line for the all shapes of bottles.
3. The machine is designed for bottles such as PVC. PE. PET etc. It can be used for different shapes of bottles.
4. The machine line with stainless steel rinse nozzles, pressure filling valve, screw capper, hot steam film shrinkage machine top quality line.
5. Filling time is controlled by the PLC.
6. The machine adopts high quality stainless steel frame(No. Z304).
7. The machine design appreance is beautiful, easy operation, maintainence and working stable
Â
| Name | Model | Technique parameter | Scheme |
|
Decapping machine  |
BG-2 Â |
Overall size: 800*500*1800 Air consumption: 0.15m 3 /min Pressure: 0.6Mpa  |
Frame: 38*38* 2mm 304 Sheet: 1.5mm       |
|
Leakage inspector  |
JL-8 Â |
Overall size: 1800*1500*2200 Power: 1.5KW Air consumption: 1m 3 /min Pressure: inspect0.2Mpa          0.6Mpa 8head rotary, inside water checking  |
Frame: A3 Outside panel: 1.5mm 304 Checking head 316 Â |
|
Outside brusher machine  |
ST-1200 Â |
Over size: 2000*1200*1500 power: 3KW main brusher 1pc , bottom brusher 4pcs water case 1pc with barrel protect system  |
frame: 38*38* 2 mm sheet: 1.5mm 304 brusher : nylon  |
|
Automatic bottle uploader  |
 |
Overall siz: 2400*1200*1000 Air consumption: 0.1m 3 /min Pressure: 0.6Mpa  |
Frame: 38*28*2 Â 304 Â |
|
Rinsing machine  |
QGF-1200 Â |
Over size : 6000*2400*2200 power: heating 18KW       other 6KW up-down rinsing, time adjusted total postion: 16heads 13heads rinsing Air consumption: 0.6m3 /min pressure: 0.6Mpa  |
Frame: 75*45*2 304 Sheet: 1.5mm 304 Pipe: stainless steel  316  |
|
Filling and capping two in one machine  |
Rotary type  |
Over size: 3800*2400*2200 Power: 5KW 12head rotary working Chain press Capacity > 1200b/h Frequency adjustable  |
Frame : A3 Sheet : 1.5 -2mm 304 Filling valve: 316  |
|
Operate controller  |
 |
Over size: 800*400*1000 Â |
2mm 304 sheet  |
|
Cap uploader and disinfector system  |
 |
Lifting style Vvolume of storage: 400pcs power: 0.37KW air consumaption: 0.05m3 /min pressure: 0.6Mpa disinfection liquid  |
 |
|
Light checker  |
DJ-2 Â |
Overall size: 600*400*200 20W*2pcs  |
304 1.5mm sheet  |
|
Shrink machine  |
 |
Steam tunnel Overall size: 800*300 Steam generator: 3KW No barrele no air spraying  |
Steam generator Automatic water feeding Steam tunnel 304 Â |
|
Bottle lifting machine  |
 |
Double head bottle lifting Overall size: 1000*500*1800 Air consumption: 0.3m3 /min pressure: 0.6Mpa  |
Frame: 38*38* 2mm 304 Sheet 1.5mm 304 Â Â |
|
Conveyor  |
 |
Empty bottle conveyor power: 3pcs*0.75KW Filled bottle conveyor power: 2pcs*1.1KW Â |
Empty bottle |
After Sale Service
Â
1. We send the engineers to help installing, commissioning and training, the engineers start from our factory area.
2. We supply below necessary documents with the machine:
  a. Machine layout
  b. Electricity diagram
  c. Machine certificate
  d. General manual book/maintenance bookÂ
Trade Information :
| Trade Terms | EXW,FOB,CFR,CIF or others |
| MOQ | 1set |
| Port | Shanghai port |
| Shipment | Ocean or air transportation |
| Payment Terms | L/C,T/T, Western Union, MoneyGram |
| Payment condition | 30%T/T |
| Supply Capability | 1 Set/Sets per Month |
| Lead Time | About 30 days |
