Small spray dryer sprays mist-like particles and instantly heats to form

Shanghai Haozhuang Instrument Co., Ltd. is a company specializing in the research, development, production and sales of cryogenic laboratory equipment and ultrasonic equipment. Mainly engaged in small spray dryers, spray dryers, experimental spray dryers, high-speed centrifugal spray dryers, small spray dryer prices, experimental spray dryer prices, high-speed centrifugal spray dryer prices and other series of scientific and experimental instruments.
Shanghai Haozhuang Instrument Co., Ltd. Haozhuang (LNB) brand small spray dryer spray dryer (spray dryer / spray dryer) and it is mainly suitable for universities, research institutes and laboratories of food, pharmaceutical and chemical companies to produce trace particles, for all Solutions such as emulsions and suspensions have broad-spectrum applicability and are suitable for drying heat-sensitive substances such as biological products, biological pesticides, enzyme preparations, etc., because the sprayed materials are only sprayed into mist-sized particles Subject to high temperature, it is only heated instantaneously, which can keep these active materials from being destroyed after drying.
1. Original imported nozzle, high efficiency.
2. Color LCD touch screen parameter display: air inlet temperature / air outlet temperature / peristaltic pump speed / air volume / needle frequency.
3. Fully automatic control: one-button start-up, after setting the spray process parameters, the temperature reaches the predetermined temperature, the peristaltic pump starts automatically, the running animation is displayed on the touch screen, the running process is clearly displayed; just press the stop button when shutting down, the machine is automatically safe Shut down.
4. Manual control: if you need to adjust the process parameters during the experiment, you can easily switch to the manual state, and the color touch screen dynamic display (animation) throughout the experiment
5. There is a nozzle cleaner (through needle), which will be automatically cleared when the nozzle is blocked, and the frequency of the needle can be adjusted automatically.
6. Shutdown protection function: just press the stop button during shutdown, the machine will stop running immediately except for the fan, to ensure that the equipment will not burn out due to misoperation (forced shutdown of the fan).
7. The spraying, drying and collecting systems are made of transparent high-quality high-borosilicate heat-resistant glass materials, so that the drying process is carried out in a non-polluting environment.
8. Built-in imported oil-free air compressor, the particle diameter of the powder spray is normally distributed, the fluidity is very good, the noise is very low, less than 60db.
9. The atomization structure of the two-fluid spray, the whole machine is made of high-quality stainless steel material, the design is compact, and no auxiliary equipment is required.
10. The design of dry temperature control adopts real-time PID constant temperature control technology to make the temperature control in the whole temperature zone accurate, and the heating temperature control accuracy is ± 1 ℃.
11. In order to keep the sample pure, equipped with air inlet filter.
12. The feed volume can be adjusted by the feed peristaltic pump, and the minimum sample volume can reach 50ml.
13. The particle size of the finished dry powder after drying is relatively uniform, and more than 95% of the dry powder is in the same particle size range.
14. For the viscous materials, there is a nozzle cleaner (through needle), which will be automatically cleared when the nozzle is blocked, and the frequency of the needle can be adjusted automatically.
15. The innovative tower wall purge device has higher material recovery rate.
Shanghai Haozhuang Experimental Instrument Co., Ltd. specializes in producing constant temperature shaker, low temperature water tank, water bath constant temperature oscillator, gas bath constant temperature oscillator, shaker and other related instruments. The factory has strong technical force, and its technical indicators are leading in China. Product selection is exquisite, exquisite workmanship, excellent quality and reasonable price. Since its establishment, the company has paid great attention to product development, upgrade and update, and constantly launched intelligent instruments with good operability and stability are the principles that Haozhuang Instruments has always followed . As always, we will provide you with safe, stable and high-performance experimental equipment to make your experimental process easier. We sincerely welcome new and old customers to visit us for common development and create brilliant!
