How to use smart artificial climate box correctly

Shanghai Xinzhuang Instrument Co., Ltd. adheres to the leading business philosophy of technological innovation and technology, and continues to make new contributions to the development of human social undertakings by carrying out strategic innovations and innovative product innovations. It is a company that integrates R&D, production and sales. Excellent product quality, excellent service, professional production of various types of laboratory equipment, Shanghai Xinzhuang Instrument Co., Ltd. welcome your inquiry http://. Intelligent artificial climate box use method
1. Plug the humidifier power into the socket on the right side of the box, and place the humidifying hose on the humidifier spray head. Put one on the humidifier inlet and add water according to the humidifier instruction manual.
2, button function operation method:
A A-1 Pull the power switch to “I”, the power light is on, and the control panel has a digital display.
A-2 "Lighting" This button is the "lighting key" of the cabinet. In the case of illuminance 0, press the button to illuminate the light, and press the button again to turn the light off. In the running state, press and hold the "lighting button". After about 3 seconds, the time window displays "Addr" (refer to the communication address, it can be ignored when there is no communication), the temperature window displays the value; then click "Settings" Query key", the time window displays "tc" (refer to temperature correction), and the temperature window displays the measured temperature correction value. The user can modify it by setting the plus or minus keys under the temperature window. Press another “Set Query” button, the time window will display “hc” (refer to humidity correction), and the humidity window will display the measured humidity correction value. The user can modify it by adding or subtracting keys. Press the “Set Query” button again, the time window displays “sbL”, and the user can set the proportional limit of humidity control. Press the "Set Query" button again to return to the running state. When shipped from the factory, Addr=1, tc=0.0, hc=00, sbL=10 (2-20%).
A-3 "Setting Query", this button is the "Set Query" button. Press this button to enter the setting state, the time indication window, temperature indication window, humidity illumination indicator window number starts to flash, the daytime indicator light is on, press the corresponding ▲▼ key to set the daytime running parameters, then press the button You can set the night running parameters, press this button again to return to the running working state, and the setting is successful.
A-4 "Day/Night", this button is the "Day/Night Switch" button, which is valid during operation and is used to restart day or night work.
A-5 "Humidity / Illumination" This button is the "Humidity / Illumination Switch" button. When the setting state is set, the humidity or illuminance can be switched. In the running state, press this button to query the current humidity or illuminance. The query is invalid during the night.
A-6▲▼ is the plus or minus key. Press this button in the setting state to add 1 and subtract 1 operations. If you hold down for 2 seconds, you will continue to add or subtract. In the running state, press 1 to increase or decrease 1 to increase or decrease the current time. If the time is reduced to 0, it will automatically enter another running state. Press 2 or 2 to display the current set temperature. Press 3 or 3 to display the current set humidity.
B. The indication window indicates various parameters during setting and operation:
B-1 period indication window: indicates that the current period is the first cycle. When the number of cycles exceeds 9, the decimal number lights up, representing ten digits. When the number of cycles exceeds 19, the decimal point flashes, representing twenty digits; when the number of cycles is 30, 0 flashes at the same time as the decimal point.
B-2 time indication window: indicates the time of setting and running. The running time is counted by the countdown method, and the unit is hour·minute.
B-3 Temperature Indicator Window: Indicates the temperature set and measured in degrees Celsius.
B-4 Humidity/Lighting Indicator Window: Indicates the humidity and illuminance of the setting and operation. The unit is %RH and percentage. A illuminance of 20% means that a group of lights is on; 40% means that two sets of lights are on; 60% means that three sets of lights are on; 80% means that four sets of lights are on; and Hi% means that all lights are fully lit.
3. Example of operation method The user requests to set the daytime time to 12 hours, the temperature of 20 ° C, the humidity of 75% RH, the illuminance of 60%, the night time of 12 hours, the temperature of 10 ° C, and the humidity of 65% RH.
Proceed as follows:
1) After power-on, first press and hold the illumination button. After about 3 seconds, the time window displays Addr, the incubator enters the system settings, and then press the set query button, the time window displays tc, and the temperature window displays the temperature correction value. The user can modify it by adding or subtracting keys under the temperature window according to the actual situation. Press the setting query button again, the time window displays hc, and the temperature window displays the humidity correction value. The user can modify it according to the actual situation by adding or subtracting keys under the temperature window; press the setting query button again to exit the system setting. State, enter the running state. Before leaving the factory, the system parameters are generally set to Addr=1, tc=0.0, hc=00sbl=10 (2~20%).
2) Press the setting query button, the number of each display window will flash, the daytime indicator will light, and the daytime running parameters can be set; press the plus 1, minus 1 button to set the control time until the time indication shows “12” hours, press plus 2. Decrease the 2 button to set the temperature charge until the temperature indication window displays “20°C”; press the 3 or 3 button to set the humidity until the humidity/illuminance indicator window displays “75% RH”; press the humidity button to light The indicator light is on, set the illuminance, press 3, minus 3 until the humidity/illuminance indicator window displays “66”%.
3) Press the setting query button again to enter the night setting, the night light is on, and the setting steps are similar to the first step.
4) Press the set query button again, the setting ends, return to the running state, and the climate box runs cyclically according to the set parameters.
,Precautions
1. In the handling of this product, it is forbidden to invert and lay flat at more than 45 degrees.
2. Do not set the temperature frequently during use, so as to avoid the overload caused by the frequent start of the compressor.
3. This product has short circuit of thermal resistance and open circuit protection. When the thermal resistance is short-circuited or open circuit, the temperature indication window displays “Err”, and the machine automatically stops heating or cooling.
4. This product has anti-icing protection. When the set temperature is lower than 10 °C, the incubator automatically stops heating.
5, the culture of the box should not be stored too much, there should be a gap in the placement, in order to facilitate air circulation inside the box.
6, should not touch, impact the temperature sensor inside the box, so as not to cause loss of control.
7. Do not wipe the surface with acid, alkali and other corrosive solutions. Wipe clean with a dry cloth. When the equipment is not in use, keep the inside of the box dry and turn off the power to set all switches to the “0” position.
8. The product must be professionally responsible for operation and maintenance. Non-electrical personnel are not allowed to overhaul the equipment. It is strictly forbidden to carry out maintenance.
9. Please read the product manual carefully before using this equipment, and then carry out various operations.
